- Easily slides in and out
- 1U; 48 FO
- 1-2 Cable entries
- Recessed adaptors for improved fibre management
- Built-in strength member tie positions
- Cable entrances sealed with oil resistance NBR to increase the flexibility
- High-quality finish
- Modular design for easy organisation – modular front plates
- Data and server racks
- FTTx
- Telecom
| Adapter Types | SC, LC, FC, ST, LC, E2000 |
| Height | 1U |
| Weight (kg) | 1.7 |
| Dimensions | 430×300×1U |
| Max Capacity | 48 fibres |
| Max Quantity of Splice Tray | 2 pcs; 12 cores |
| Optical Fibre Winding Radius | ≥40mm |
| Fibre Length Left In Tray | ≥1.6m |
| Working Temperature | – 400C ~ + 600C |
| Lateral Pressure-Resistance | 500N |
| Shock-Resistance | 750N |
| Material | Cold-Rolled Steel (Powder Coated) |
