- UL & 3P Certified
- Space-saving high-density 1U
- Meets or exceeds the requirement proposed by TIA /EIA 568 B.2, ISO/IEC 11801 Category 3
- Black electrostatic powder-coated corrosion-resistant steel
- Sturdy aluminium plate around jacks
- Termination accepts 22, 23, 24 and 26 AWG (0.64-0.4) solid wires
- Easy wiring installation fit for 110 punch-down tools
- Phosphor Bronze, 6-50 micro inches gold plated
- Telecommunications
- LAN
| Insertion Life | 750 cycles minimum |
| IDC Life | 200 times (22-26 AWG solid wire) minimum |
| Plug/Jack Contact Force | 100g minimum using FCC-approved plug |
| Insulation Resistance | 100Mohms minimum |
| Contact Resistance | 7Mohms maximum |
| Dielectricity Intensity | AC 1000Vrms, 50Hz or 60Hz in 60s |
| Plating | Silver/Gold |
| Plating Thickness | 1.25um, 5um/ 3u”, 6u”, 15u”, 30u”, 50u” |
