- 250 MHz with over 2.5Gbps
- 25 Years Warranty
- Foiled/Unscreened
- LSZH or PE jacket
- Available in different colours
- Available in different lengths
- Durable for 750 insertion cycles
- Data centre & Telecommunication networks
- LAN Applications
- CATV – Cable television, CCTV
| Structure | 4 x 2 AWG 26, twisted pair |
| Jacket | LSZH or PE |
| Configuration | 1:1 |
| RJ45 connector | 3 μ nominal gold flash over 60 μ nickel undercoat contact pins |
| Wiring standard | EIA/TIA 586B |
| Input impedance | 100 Ohm |
| Dielectric strength | 2500 VDC for 3 seconds |
| Uninsulated resistance | 150 MΩ/km minimum |
| NVP | 76% |
| Flame retardance, Smoke emission | IEC 60332-1, IEC 61034 |
| Typical applications | IEEE 802.3: 10BASE-T; 100BASE-T; 1000BASE-T |
| Norms | ISO/IEC 11801-1; EN-50173; ANSI/TIA 568-C; EN 60603-7-5 |
