- IDC connecting technology
- Suitable for use in all xDSL and ADSL 2+ circuits
- Flexible indoor and outdoor use
- Robust long-term stability
- Overvoltage protection
- Available in 8 or 10 pair
- Designation labelling system
- Compatible with KRONE LSA-PLUS Modules
- Available with metal profile
- Other colours available
- Telecommunications
- LAN
| Insertion Life | 250 cycles minimum |
| IDC Life | 200 times (22-26 AWG solid wire) minimum |
| Material | PBT/ABS (UL94V-0) |
| Insulation Resistance | ≥1000MΩ |
| Contact Resistance | <7MΩ |
| Dielectric Intensity | DC 1200V, 60s no spark over and fly arc |
| Conductor Diameter | AWG 22-26 (0.4-0.63mm) |
| Contact Material | Brass – silver-plated |
| Operating Temperature | -10 to +60°C |
| Conformance | RoHS, EC European Directive 2002/96/EG |
