- Gigabit Ethernet acc. to IEEE 802.3
- 10 Gigabit Ethernet acc. to IEEE 802.3an: Adequate for 10 Gigabit Ethernet
- RJ45 female, 8P8C
- Tool-free cable installation according to EIA/TIA 568 A & B
- Screw locked
- 360° shield coverage
- AWG-range: 24 … 22
| Category | CAT 7 |
| Contact Height After Crimping | 6.02mm ± 0.13mm |
| Durability Test | 750 times |
| Dielectric Voltage Withstand Test | Test 60S 1000V AC/DC TEST PASS |
| Tensile Test | ≥ 20pround (9.1kg) |
| Latch Bending Test | Over 20 times |
| Operating Temperature Range | -40 ~ 70C |
| Storage Temperature Range | -40 ~ 70C |
