- Allows quick installation of fibre optic cable
- Capacity can be adjusted as necessary
- Built-in direct splice unit
- RoHS materials
- Lockable Door
- Glass or solid front door
- Telecommunication networks
- LAN, MAN and WAN applications
- CATV – Cable television
- Fibre-to-the-Home (FTTH)
| Material | Cold-Rolled Steel |
| Dimensions | 750x2200x600mm |
| Splice Tray Qty. | 32pcs |
| Max Capacity | 512 Fibres |
| Plinth | Different heights available |
| Cable management | Side-mounted cable spool |
| Weight | 135kg |
| Nominal Work Wave-Length | 850nm, 1310nm, 1550nm |
| Operating Temperature | -10ºC-+60ºC |
| Storage Temperature | -40ºC +70ºC |
| Relative Humidity | ≤85%(+30ºC) |
| Atmospheric Pressure | 70~106 KPa |
| Insertion Loss | ≤0.3dB |
| Return Loss | ≥45dB (PC), ≥50dB (UPC), ≥60dB (APC) |
| Isolation Resistance | ≥1000MΩ/500V(DC) |
| Durability | >1000 times |
| Anti-Voltage Strength | ≥3000V(DC)/1min |
