- Cost effective solution for in house termination.
- Low insertion loss and added loss.
- Height of attenuation.
- IP67 water, dustproof and corrosion resistant
- Mechanical performance: IEC 61754-4 standard.
- RoHS and REACH materials compliant.
- Cable diameter Range: 2.0*3.0mm Ftth drop cable
- FTTH & Outdoor Fibre Terminal End
- Harsh Environment
- FTTA BBU RRU
- Data Video Transmission
- Optical Fibre Access Of Mobile Base Station
| Cable Scope | 2*3.0mm flat drop cable |
| Fibre Diameter | 125μm (652 & 657) |
| Coating Diameter | 250μm |
| Mode | SM |
| Operation Time | About 15s (exclude fibre presetting) |
| Insertion Loss | ≤0.3dB (1310nm & 1550nm) |
| Return Loss | ≥ 50dB for UPC, ≥ 55dB for APC |
| Success Rate | >98% |
| Reusable Times | >5 times |
| Tensile Strength | >30 N |
| Temperature | -40~+85℃ |
| On-line Tensile Strength Test (20 N) | IL ≤ 0.3dB |
| Durability (500 times mating) | IL ≤ 0.3dB |
| Drop Test (4m concrete floor, once each direction, three times total) | IL ≤ 0.3dB |
