We offer a full range of fibre patch cords in simplex & duplex, various connectors and cables in different colours, as well as different thickness of jackets 900um, 2 and 3mm. Some connectors have extra options for Uni-Boots, Angled Boots & Short Boots.
- Polarity switchable option available
- Unique push-pull design and function
- IEC 61754-20 Standard
- Uniboot with a single housing
- Low insertion loss and added loss
- Height of attenuation
- High back loss, small volume, light weight
- End-face geometry and quality superior than IEC and Telcordia standards
- LSZH, OFNP, OFNR cable jacket
- RoHS and REACH compliant materials
- Multi-purpose outdoor
- For the connection between the distribution box and RRH
- Deployment in remote radio head cell tower applications
| Mode
Fibre Types |
Single Mode G652D/G655/G657A2/G657B3 |
Multimode OM1/OM2/OM3/OM4/OM5 |
|
| Polish | UPC | APC | PC |
| Insertion Loss (dB) | ≤0.30 | ≤0.20 | ≤0.20 |
| Return Loss (dB) | ≥50 | ≥60 | ≥30 |
| Test Wavelength (nm) | 1310/1550 | 850/1310 | |
| Durability (500 matings) | ≤0.2 | ||
| Operating Temperature (⁰C) | -40~60 | ||
| Storage Temperature (⁰C) | -45~85 | ||
| Fire Resistant | IEC 60794-2-30 | ||
| Standards-Compliant | ROHS, IEC and GR-326 | ||
| Connector | SC/PC, SC/APC, LC/PC, LC/APC, FC/PC, FC/APC, ST/PC, E2000/PC, E2000/APC, MU/PC, MTRJ/Female, MTRJ/Male, MPO/MTP, DIN/PC, SMA/PC, D4/PC | ||
| Cord Type | Simplex, Duplex | ||
| Cable Diameter | 0.9mm ,1.2mm, 1.6mm, 1.8mm, 2.0mm, 2.8mm, 3.0mm, 4.1mm | ||
| Cable Jacket | PVC, OFNR, LSZH, OFNP | ||
| Length | 0.5m, 1m, 2m, 5m, 10m, 25m, 50m, 100m or Custom | ||
