These cables allow network installations to be simplified by direct connection; bypassing wall boxes, ODFs or fibre patch panels, resulting in greatly improved fibre management.
- 3 x fibre density of LC duplex adapters
- Push-pull boot
- Individual high strength aramid yarn strength members for ease of handling
- Very Small Form Factor (VSFF)
- Multimode OM3, OM4, OM5
- Data centres
- Storage area networks
- Short-distance connections
| Fibre Types | OM3, OM4, OM5 |
| Fibre Capacity | 12 |
| Cable Construction | Round double jacket cable |
| Jacket Material | LSZH |
| Outer Diameter | 3.0/4.5 mm |
| Operation Temperature | -10°C to +70°C |
| Storage Temperature | -25°C to +70°C |
| Installation Temperature | -5°C to +50°C |
| Compliance | Telecordia GR-326 |
| Colour of Housing | Blue (UPC), Green (APC), Aqua, Magenta, Lime Green |
| Insertion Loss | <0.25dB (@850/1300nm & @1310/1550nm) |
| Return Loss | >50dB (UPC) (@1310/1550nm) >65dB (APC) (@1310/1550nm) >20dB (@850/1300nm) |
