- IP68 & IK10 rating (Harsh environment & temperatures)
- 48 FO
- Very strong & robust shell
- Mechanical sealing cable entries
- RoHS materials
- Telecommunication networks
- LAN, MAN and WAN applications
- CATV – Cable television
- Fibre-To-The-Home (FTTH)
| Usage | Aerial; Manhole; Wall; |
| Dimensions | (450×φ230)mm |
| Cable Entries | 5 entries @ 10-17.5mm |
| Weight | 4.4 ~ 4.8 Kg |
| Type of Seal | Mechanical |
| IP Rating | IP68 |
| Box Material | Polymer Modified Plastic |
| Sealing Material | Vulcanised Silicone Rubber |
| Splice capacity per tray | 24 (18 SC SX Adaptor ports) |
| Maximum Splice Capacity per enclosure | 48 ( 1X16 SC SX or 2X16 SC SX) |
|
Included Accessories
|
Splice trays, cable ties, cable fixings, pole-mounting hoop, sandpaper, Sealing gasket, splice protection sleeves, silver paper, insulating tape |
