| Dimensions (mm) | 210x175x50 |
| Material | PP plastic |
| Adapter port | 9 pcs SC Simplex (when using 1×8 splitter) |
| Max. Capacity | 12 fibres (splicing) |
| Colour | White |
| Application | Outdoor wall mounted/indoor soft cable |
| IP rating | IP65 |
| Product | ITB (Indoor Subscriber Terminal Box), IDB (Indoor Distribution Box), OTB (Outdoor Subscriber Terminal Box), ODB (Outdoor Distribution Box), ISB (Indoor Splitter Box), OSB (Outdoor Splitter Box) |
|---|---|
| Model | 01, 02, 03, 04, 05, 06, 07, 08, 09, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32 |
| Material | P Plastic, M Metal |
| Adapter Type | FC, LC, SC, ST, E2, MTP |
| Polish Type | A (Angled), U (Unpolished) |
| Capacity | SX, DX, QD |
| No of Fibres | 01, 02, 04, 06, 08, 09, 10, 12, 16, 17, 24, 36, 48, 72, 96, 120, 144, 192 |
| Additonal | /P Pigtails, Blank if unloaded |
Distribution Boxes
Outdoor Splicing Distribution Box – Metal – Model 05 – 48 FO
Distribution Boxes
Outdoor Splicing Distribution Box – Metal – Model 07 – 192 FO
Distribution Boxes
Outdoor Splitter Distribution Box – Plastic – Model 04 – 24 FO
Distribution Boxes
Distribution Boxes
Outdoor Splicing Distribution Box – Plastic – Model 01 – 36 FO
Distribution Boxes
Outdoor Splitter Distribution Box – Plastic – Model 08 – 12 FO
Distribution Boxes
Distribution Boxes
