Special Cable Organiser 24 Port Modular Patch Panel – Model 01

Name: Special Cable Organiser 24 Port Modular Patch Panel - Model 01
SKU: EMUTPSCP24BLK1U01-1
Availability: InStock

These special cable organizing patch panels are exclusively designed by BCP®. Model 02, 24 Ports – Modular, has a unique loop cable organizing system to enable easy and secure cable management. The cable holders suit cable diameter up to 9.4mm. Made from hard plastic with a good bending capability the holder contracts around the cable to hold it in place securely.

Empty

Construction

Product

Port Density

Colour

Unit

Clear

Add to wishlist

Example PN: EMUTPSCP24BLK1U01-1 Category: Cat 8

general information
Additional information

Exclusive Briticom design
Flat front plate
25-year warranty
Labelled Ports
ANSI/TIA-568-C.2 & ANSI/TIA-568.0-D
19” 1U
Suitable for Cat 8 to Cat 5
24 ports and adjustable cable slots
Suitable for 5.1-8.8mm cables

Data and server racking
Data centres
LAN installations

Patch Panel
Norms	ISO/IEC 11801 3rd Ed., EN 50173-1, ANSI/TIA-568-C.2, ANSI/TIA-568.0-D
Housing Material	1.5 mm SPCC cold rolled steel sheet, powder-coated
Material Standard	EN 10 130(1991), BS 1449, NFA 36/401, DIN 1623, UNI 5866, ASTM, SAE, NFA 36/401
Grounding	Central ground connection
Operation Temperature	-20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA-568-C.2, ANSI/TIA-568.0-D)

Cable Organiser Bar
Width	19”
Depth of Rear Bar	28mm
Overall Height	42mm
Overall Depth (from back of empty panel)	94mm

Cable Organiser Slots
Slot Quantity	24 (2 rows of 12)
Locking Positions	6 nodes
Cable Diameter	5.1-8.8mm
Distance Between Each Slot	17.10mm
Depth of Locking Arm	4.9mm
Rotation	180°
Full Height of Slot	Largest: 16.6mm; Smallest: 12.2mm
Overall height of management system	29mm
Lock Type	Quick release

DOWNLOAD DATASHEET

Empty	EM
Construction	UTP (UTP), STP (STP)
Product	PP (IDC/PCB Panel), KP (KSJ Panel), VP (V-Shaped), FP (Foldable), FV (Foldable V-Shaped), SP (Shuttered Ports), CF (Coloured Front), CS (Coloured Shuttered), MF (Modular Flat), MV (Modular V-Shaped), LT (Light-Tracing), IG (Intelligent), IV (Intelligent V-Shaped), KV (KSJ V-Shaped), KVS (KSJ V Shuttered), KMF (KSJ Modular Flat), KFV (KSJ Foldable V-Shaped)
Port Density	1-24, 24, 48
Colour	BLK
Unit	0.5U, 1U, 2U, 3U, 4U
