The Briticom™ Visual Fault Locator 1Mw is an essential tool for any engineer or technician. This allows quick and easy detection of faults in fibre installations, such as breaks or faulty connectors, by pinpointing the location of the signal loss. Therefore, problems can be diagnosed and fixed efficiently. The Visual Fault Locator 1Mw can also be used for end to end continuity tests and perform fibre identification. Its compact size and long-lasting battery mean its ideal for the quick and easy location of damage in fibers. It comes with a soft sided carry case with a belt loop for easy transportation in the field.
Already bought this product from us? Share your experience on LinkedIn
- Compact size
- Soft-sided carry case with belt loop
- Quick & easy location of damage in fibres
- Continuous & flashing illumination models
- Designed for demanding field use
- Long-lasting battery life
- Protective rubber end cap
- One-year warranty
| Wavelength | 650nm | |||
| Emitter Type | Laser (Class 2) | |||
| Output Power | 1.0 mW max | |||
| Distance Range | > 7 km (single-mode); > 5 km (multi-mode) | |||
| Operation Mode | Pulsed & CW | |||
| Power Supply | 2 x AA batteries | |||
| Battery Life | > 30 hours | |||
| Connector Type | Universal 2.5 mm; Universal 1.2 5mm | |||
| Dimensions (mm) | 110 (l) x 34 (w) x 20 (h) | |||
| Weight (g) | 40 | |||
