- Fully compatible with other MTP based fibre system
- Easy installation
- No specialist tools or equipment required
- 100% modular
- Quickly add 12 LC ports to your network at a time
- Small bend radius allows for high-density networking without loss of performance
- LAN networks
- Data centres
- Telecommunication networks
- Cable trays
| Fibre Types | OM3, OM4, OS2 | ||
| Polarity | C (standard). A and B available | ||
| Fibre Capacity | 12 | ||
| Glass Fibre | Corning | ||
| Fibre Construction | Dry loose tube micro cable | ||
| Outer Diameter | 3.0mm (single sheath), 4.5mm (dual sheath) | ||
| End 1 | MTP® ELITE 12 Fibre Connector | ||
| End 2 | LC/UPC duplex low loss connector (x6) | ||
| Insertion Loss Across Cable | < 0.35 dB + cable loss | ||
| Cable Material | LSZH | ||
| Weight kg/Km | 8 (single sheath), 23 (dual sheath) | ||
| Min. Bend Radius | 10 x (outside diameter) | ||
| Max. Crush Resistance | 150 N/dm (single sheath), 300N/dm (dual sheath) | ||
