Britanic Cabling Production designs and manufactures unique and robust patch panels. Our patch panels use various technologies for easy access and organisation: these include pivots, sliding on rail and easy sliding. Many of our panels are also modular, to further aid the user.
| Height | 4U (3U + 1U) |
| Dimensions | 484x349x178mm |
| Adapter Types | SC, LC, FC |
| Material | Cold-Rolled Steel, ABS |
| Weight | 6.5kg |
| Capacity | 144 (SC), 288 (LC & FC Duplex) |
| Type | LR |
|---|---|
| Unit | 4U |
| Model | 3 |
| Adapter Type | LC, SC, FC |
| Polish Type | U Flat, A Angled, Fibre management only |
| Mode | SX, DX, QD |
| Fibre Type | M Multimode, S Single-mode, E Empty, A1 G657A1, A2 G657A2, B3 G657B3, M1 OM1, M2 OM2, M3 OM3, M4 OM4, M5 OM5, S2 OS2 |
| Fibres/Ports | 144, 288 |
| Extra Options | F Fibre Management, P Pigtails, A Adapters only |
