Britanic Cabling Production offers a wide range of indoor and outdoor fibre optic distribution, patching and consumer cables – including Plenum, Riser and LSZH in all diameters. These are used to provide links to protocols such as FTTH, FDDI, 10 Gigabit Ethernet, ATM.
| Fibre Count | 1 to 2 |
| Outer Diameter (mm) | 6.8 |
| Weight per Km | 47kg |
| Max Tensile Strength (N) | 200 |
| Min. Bend Radius (mm)
Dynamic Static |
20 10 |
| Max Crush Resistance (N/mm2) | 1000 |
| Operating Temp. (⁰C) | -20 to 60 |
| Connector | FDC (Flat Drop Cable), RDC (Round Drop Cable) |
|---|---|
| Fibre Type | S1 (OS1), S2 (OS2), M1 (OM1), M2 (OM2), M3 (OM3), M4 (OM4), A1 (G657A1), B3 (G657B) |
| Strength Members | SW (Steel Wire), FRP (FRP Member), K (Kevlar), AY (Aramid Yarn) |
| Colour | YEL, BLK, WHT, AQU |
| No of Fibres | 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 |
| Material | HD (High-Density Polyethylene), PV (PVC), LS (LSZH), PE (Polyethylene), LD (Low-Density Polyethylene), DJ (Double Jacket PE/PVC), DJHD (Double Jacket HDPE), SJHD (Single Jacket HDPE), SJPE (Single Jacket PE) |
| Additional | FI (Flat Inside Round), SM (Steel Wire Messenger), FRPM (FRP Messenger), FRPM8 (Figure 8 FRP Messenger) |
