- Up to 1.4Gbps data rate
- Built-in 2 port switch which supports flow and bandwidth control
- SFP transceiver technology allows adaptions, without replacing media converters
- Built-in RAM for data buffer
- Compliant to IEEE 802.3*, FCC and CE standards
- Card-type and media racks also available
- LAN Applications
- CCTV
| Cable | SM or MM Fibre/Twisted Pair |
| Transmission Type | 10/100/1000M FDX/HDX |
| Wavelength (nm) | 850~1625 |
| Bandwidth | 1.4Gbps |
| Data Buffer | 2Mb |
| Distance | 550m~120km |
| Operating Temperature | 0 to +70 |
| Weight (kg) | 0.2 (External Power) |
| Dimensions (External Power) (mm) | 95(L) * 70(W) * 26(H) |
| Power Consumption | 3.5W |
| Operating Humidity (%) | 5 – 90 |
| Power External | DC5V 2A |
| LED indicator | POWER (power supply) FX Link/ACT (fibre link/action)
TX Link/ACT (RJ45 link/action) 100M, SD |
| Error Rate | < 10-9 |
| Transmission Distance(km)
(m) |
Multi-mode Dual-fibre 2 Single-Mode Dual-fibre 20/40/60/80/120
Cat5 Twisted Pair 100 |
| Port | RJ45 Port: Connecting with STP/UTP Cat5 Twisted Pair
Optical Port: SC ST FC |
| Conversion Means | Media Conversion, Store-and-Forward |
