- 16 FO
- 1×8 Micro Mini PLC Splitter x 2
- SC Simplex Adapter x 16pcs
- Fusion Splicer x 16 fibres
- IP65 & IK10 Rated (Harsh environment & temperatures)
- UV Resistant
- RoHS materials
- For use outdoors
- Telecommunication networks
- LAN, MAN and WAN applications
- CATV – Cable television
- Fibre-To-The-Home (FTTH)
| Dimensions | 274×175×82mm |
| Material | ABS + PC |
| Max. Capacity | 1×8 Micro Mini PLC Splitter – 2pcs
SC Simplex Adapter – 16pcs Fusion Splicer – 16 fibres |
| Insertion Loss | ≤0.2dB |
| Return Loss | ≥50dB (UPC), ≥60dB (APC) |
| Insertion Life | >1000 times |
| Working Temperature | -40⁰C ~ 60⁰C |
| Relative Humidity | ≤85% (+30⁰C) |
| Atmospheric Pressure | 70KP~106Kpa |
| Colour | Grey |
