Cat 7 Keystone Jack – STP Tool-Free 180°

Cat 7 Keystone Jack – STP Tool-Free 180° (1)-2

Cat 7 Keystone Jack – STP Tool-Free 180°

Name: Cat 7 Keystone Jack - STP Tool-Free 180°
SKU: STPC7TJ180SLV-E
Availability: InStock

Britanic Cabling Production Category 7 Screened STP Keystone jack Modules are designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards available in a choice of 90°, 180° shuttered and non-shuttered. This delivers Class FA link and channel performance supporting all applications detailed and proposed within the standards. This superior performance cable is ETL Component Verified.

Construction

Category

Type

Jack Style (degree)

Colour

Standard

Additional

Clear

Add to wishlist

Example PN: STPC7TJ180SLV-E Category: Cat 7

general information
Additional information

Shielded (STP)
Tool Free
180 degree fit for loading a full STP/UTP 24/48 port patch panel
Contact mating area – gold plating option (3U”,6U”,15U”,30U”,50U”) over Nickel
Dual IDC Type termination
RoHS compliant

Voltage Rating	125 VAC RMS
Current Rating	1.5AMP
Contact Resistance	110 Milliohms MAX.
Insulation Resistance	1 000 megohms MIN 500 VDC
Dielectric Strength	750 VAC RMS 60Hz ,1 MIN
Wire	AWG 24-26
RJ45 Jack Life	750 times MIN.
IDC Life	200 times MIN.
Contact Material	Phosphor Bronze stamping pin at a thickness of 0.35mm PC-UL90V-0
IDC Material	Phosphor Bronze at a thickness of 0.5mm and Nickel plating
Housing Material	ABS or PC, PBT-UL90V-0
Conformance	RoHS compliant. TIA/CAT6, 568A/568B

DOWNLOAD DATASHEET

Construction	UTP, STP
Category	C7
Type	KJ (Keystone Jack), IC (Inline Coupler), TJ (Tool Free KSJ), PT (Pass-Through), WJ (Waterproof KSJ Coupler), 36 (360-degree), LJ (Locked), SJ (Shuttered), SL (Shuttered & Locked), TL (TF and locked), TS (TF and shuttered)
Jack Style (degree)	180, 90
Colour	SLV, BLK, GRY, WB
Standard	-E (Extra Range), -P (Platinum)
Additional	OD (Outdoor), Blank if Indoor
