BCP® Our steel wire armoured cable is super robust and has excellent crush resistance, The fibre optic strands are protected by a strong steel wire armour, a double jacket and also a water blocking filling gel. This enables the cable to be suitable for buried and horizontal applications.
Already bought this product from us? Share your experience on LinkedIn
- For outdoor use
- PE and flame-retardant LSZH sheath options
- Steel wire strength members
- Direct burial
- Water, flame and rodent resistant
- Available in many colours
- IEC 60332-1 & 3 IEC 60228
- Long Outdoor distance communication
- Inter-office communication
- Steep slopes and river / undersea crossing
- Very harsh environmental conditions
| Fibre | Type | G652D |
| Number of fiber | 12F | |
| Number of fibers per tube | 12 | |
| Number of Loose tube | 1 | |
| Loose tube | Material | PBT |
| Diameter | 1.8mm | |
| Water Blocking layer (Material) | Flooding Compound | |
| Strength member | Material | Steel wire 0.6mm |
| Installation Temperature range ºC | -40+80 | |
| Operation and transport temperature ºC | -40+80 | |
| Min Bending Radius(mm) | Long term | 15D |
| Min BendingRadius(mm) | Short term | 30D |
| Tensile Strength(N) | Long term | 3000 |
| Short term | 4000 | |
| Crush Load (N/100mm) | Long term | 3000 |
| Short term | 4000 |
